Mod Jacks 4, 6, 8 & 10 Positions, Thru-hole, SMT, Right Angle, Vertical, Shielded, LEDs, Ganged, Stacked, Integrated Magnetics

RF Connectors Wide selection of cable, panel mount & PCB connectors. BNC, TNC, FMA, FME, SMA, SMB, N, F PAL Mini-UHF, MCX, MMCX, W.FL & 1.6/5.6

Small Form Factor Industry Standard Compatibility Interfaces with both fiber optic and copper networking modules Single, Stacked or Ganged Cages

Display Port & Mini-Display Port High band width digital interface Small package, shielded design Supports color depth 6,8,10,12,16 bits per color components

IDC Connectors 1.27, 2.00, 2.54mm Pitches 8P – 100P Dual Row Sockets, PCB Plugs Card edge, D-Subminiatures

DVI Connectors Digital & Analog versions Straight and Right Angle PCB mount High Speed performance and low cost Single or Dual Stacked

1.27mm SCSI II/III Right Angle Right Angle & Vertical mount 20P – 120P, Metal EMI protection front shell Multiple Panel and PCB mounting options

Centronics/Miniature Ribbon Connectors Straight pin or Right Angle pin PCB mount Solder cup, Flat Cable IDC versions. 14P, 24P, 36P & 50P Multiple panel and PCB mounting options

USB, Mini-USB, Micro USB & Firewire, Mini-Firewire USB 2.0 & 3.0 Standard, Mini & Mirco versions Types A, AB, AB1, B, B4 & B5 Firewire & Mini Firewire styles Thru-hole, SMT, Stacked versions

SATA Series Meets SCA Interconnection Standards Hot Plug capability with power and signal contacts Single and top/bottom or side/side ports Shielded, Open Frame, Thru-hole & SMT styles

HDMI & MINI HDMI Series Standard or Mini types, Sturdy, Fully Shielded Eliminates multiple connectors and cables Up to 5Gbps in single interface Thru-hole or SMT mount, Flange mounting option

AC Inlet & Outlet Power Connectors IEC & Mini-IEC types IEC-60320, CEE-22 Compliant Solder, Quick connect or PCB pin mount Snap in or Screw in Flange Mount Fuse & Fuse with Switch versions Inlet & Outlets with Power Line Filters

PLCC Sockets Full range 20p – 100p Precision Stamped contacts Thru-hole and SMT types Standard and Hi-Temp versions

FPC & FFC Flex Circuit Series 0.3, 0.5, 0.8, 1.0 & 1.25mm Pitches LIF and ZIF types Precision Stamped High Pressure contacts Thru-hole or SMT versions 03– 30 Positions

DC Power Jacks Miniature & Sub-Miniature PCB and panel mounting versions Wide range of center pin sizes Thru-hole or SMT mounting

Audio Jacks Miniature & Sub-Miniature styles Broad range of switching configurations Ganged and Stacked versions PCB or panel mounting types Thru-hole or SMT mounting

RCA Jacks Wide range of body styles Ganged and Stacked versions Industry standard compatibility

DIN, Mini DIN & Power DIN Jacks Wide range of styles 3 – 13 positions Shielded or Unshielded PCB mount and Panel mount versions

Pin Headers Many Pitches including: 0.8, 1.0, 1.27, 2.0, 2.54 & 3.96mm Straight, Right Angle Thru-hole & SMT Custom pin lengths

Shrouded & Latch Headers

Receptacle Stips Many Pitches including: 0.8, 1.0, 1.27, 2.0, 2.54, 3.96mm Straight, Right Angle Thru-hole & SMT

Memory Connectors Memory Sticks, Smart Media Compact Flash, Secure Digital, PCMCIA

Terminal Blocks Wide range of sizes and profiles Choice of multiple terminations 02 – 30 positions

Euro Blocks Multiple sizes and profiles Top, Side and Angled entry Two piece pluggable versions 3.5, 3.81, 5.0, 5.08, 7.0, 7.62, 10.0, 10.16, 15.0mm Pitches

Power Cords International selection of plugs and cable Sturdy High Reliability design Worldwide Safety Agency approvals Standard and custom power cords

Battery Holders, Battery Snaps, Mobile Battery connectors Single and multi package Alkaline battery holders. Selection of Lithium Coin cell holders, PCB Mobile Battery holders. Wide selection of 9 Volt battery Snaps.

D-Subminiatures Solder cup, R/A PCB, Straight PCB & IDC types Right Angle PCB mount offered in .318" (8.08) & .590" (15.00) footprints Wide assortment of mounting options available Positions: 9, 15, 25, 37, 50 Compatible with all industry standard D-Subs

Wire to Board Connectors Power connectors, high current rated Polarized and Non-Polarazied types Multiple configurations and Industry standard compatible Pitches: 3.0mm, 4.14mm, 4.2mm & 6.35mm

IC Sockets High Pressure contact system 7.62 (.300") or 15.24 (.600") Centerline Footprint 06P – 48P Positions Anti-Solder Wicking, Machine insertable

EMI / RFI Power Line Filters Numerous terminations for Chassis or PCB Mount Integrated Power Inlet/Outlet Power Entry modules available Superior Common & differential mode attenuation

Mini Flex Connectors 1.27 (.050") Pitch Cable-PCB, Wire-PCB, PCB-PCB Styles Superior design with Location Pegs & Friction Lock Mating

DIN 41612 Industry standard Types, R, C, Q Standard & Inverse, Full and ½ types 2, 3 & 4 Row configurations

INTRODUCTION AND PROMISE

Adam Tech is pleased to provide you with our 2012 catalog in our 21st year of business. It is our continuing goal to offer a wide range of world class connectors and cable assemblies with one simple promise: We will provide you with the Highest Quality Product with the Best Service Available at the Lowest Possible Price.

CAPABILITIES

We pride ourselves on the scope of our product offering which features our innovative connector designs and manufacturing capabilities that reduces cost and improves performance in a broad range of applications. Our exclusive automated manufacturing processes provide consistent high quality with low cost and short lead times. We also welcome the opportunity to use our experience in providing custom solutions to your application specific product requirements. We can develop concepts into designs, tooling and production.

SALES, SERVICE & AVAILABILITY

Adam Tech has a professionally staffed sales team at our corporate headquarters in Union, New Jersey, USA which is fully stocked with many of our standard products. From this location and from thirty representative offices located throughout North America, Europe and Asia we provide worldwide service to all of our customers and their contract manufacturers. In addition, our manufacturing and stocking facilities in Taiwan and China are available for local engineering, sales and product support. Adam Tech products are also available internationally through our network of experienced distributors who also offer local stock and value added services. Please check our website for a complete listing of our representative offices and distributors.

ENVIRONMENTAL

Adam Tech is committed to the elimination of hazardous materials in our products for the protection of our environment and human health. We have taken steps to provide products that are lead-free and free from other hazardous materials. Adam Tech’s products are all fully compliant to RoHS directive 2002/95/EC with no exemptions.
